5-axis machining center KAFO KFO 620 5AX, built in 2019

• Equipped with Heidenhain TNC 640 control

• Travel paths X/Y/Z: 620 x 520 x 460 mm

• Rotary table Ø650 mm, 5-axis simultaneous capability (B-/C-axis integrated)

• Max. workpiece weight: 300 kg

• Spindle: Direct drive, 12,000 rpm, SK40, 10 kW (S1), 15 kW (S6)

• Tool changer: 30-fold, automatic round magazine changer

• Coolant system with high pressure (IKZ 20 bar)

• Machine weight: approx. 7,800 kg

• Dimensions (LxWxH): approx. 4300 x 2400 x 3200 mm

• Chip conveyor and coolant pump integrated

• Machine hours (display):

• Spindle time: approx. 1,989 h

• Machine running time: approx. 7,187 h

• Program run: approx. 2,728 h

• Condition: Very well maintained, ready for immediate use, visually and technically good

• Solid Taiwan machine, high precision, good alternative to DMG, Hermle etc.

• Sale incl. control panel, cabling, without clamping devices or CAM
